Cadre
Genius Alloy 6061
Integrated Suspension Technology
Virtual 4 Link kinematic / Adjustable head angle
Syncros Cable Integration System
BB92 / UDH Interface / 12x148mm with 55mm Chainline
Fourche
FOX 36 Float Rhythm Air Grip
3-Modes / 15x110mm QR axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 160mm travel
Amortisseur arrière
FOX Float Custom EVOL Performace Trunnion
3 modes / Lockout-Trail-Descend
DPS / Reb. Adj.
Travel 150mm / T185X55mm
Levier de contrôle
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Dérailleur arrière
Shimano XT RD-M8100 SGS
Shadow Plus / 12 Speed
Manettes de dérailleur
Shimano Deore SL-M6100-R / Rapidfire Plus
Pédalier
Praxis Cadet M24HD
55mm CL / 32T
Guide-chaîne
SCOTT custom
Boitier de pédalier
Praxis M24 BB92 / shell 41x92mm
Chaîne
Shimano Deore CN-M6100
Cassette
Shimano Deore CS-M6100-12 / 10-51 T
Freins
SRAM DB8 4 Piston Disc
Disque de frein
SRAM Centerline CL Rotors 200/F and 180/R
Cintre
Syncros Hixon 2.0 Alloy 6061 D.B.
12mm Rise / back sweep 8° / 780mm
Syncros Endurance lock-on grips
Potence
Syncros AM 2.0
Syncros Cable Integration System
4° rise / 6061 Alloy / 31.8mm / 1 1/8″
Tige de selle
Syncros Duncan Dropper Post 2.5
31.6mm / S size 125mm / M size 150mm / L & XLsize 170mm
Selle
Syncros Tofino 2.5 Regular
Jeu de direction
Syncros – Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Moyeu avant
Formula CL-811 / 15x110mm
Moyeau arrière
Formula CL-148M / 12x148mm
Rayons
Stainless Black 15G / 1.8mm
Jante
Syncros X-30S / 32H / 30mm / Sleeve Joint
Tubeless ready
Pneu avant
Maxxis Dissector / 60TPI Foldable
Tubeless Ready / EXO
Pneu arrière
Maxxis Dissector / 60TPI Foldable
Tubeless Ready / EXO
Extras
Syncros Fork Fender
Poids en Kg (App.)
15.5 (Tubeless setup)
