Cadre
Carbon HMX
Integrated Suspension Technology
Flex Pivot / Adjustable head angle
Syncros Cable Integration System
TQ HPR50 / UDH Interface / 12x148mm with 55mm Chainline
Débattement
Front: 140mm / Rear: 130mm
Fourche
FOX 34 Float Rhythm Air Grip
3-Modes / Kabolt 15x110mm axle / tapered steerer
44mm offset / Reb. Adj. / Lockout / 140mm travel
Amortisseur arrière
FOX NUDE 6T EVOL Trunnion
SCOTT custom w. travel / geo adj.
3 modes: Lockout-Traction Control-Descend
Low Speed Adj. / Custom large Air volume / Reb. Adj.
Bearing Hardware / Travel 130-90-Lockout / T165X45mm
Levier de contrôle
SCOTT TwinLoc 2 Technology
Suspension & Dropper Remote
3 Suspension modes
Assistance électrique
TQ HPR50
Moteur
TQ HPR50 Mid Motor drive 50Nm max Torque / EU: 25kmh / US: 20mph
Batterie
TQ Internal 360Wh
Ecran
TQ HPR
Bluetooth / ANT+ / Dedicated Smartphone app
Chargeur
TQ 100-240V-4A
Dérailleur arrière
SRAM S1000 Eagle AXS Transmission 12 Speed
Wireless Electronic Shift System
Manettes de dérailleur
SRAM AXS Pod Controller
Pédalier
FSA Alloy
Guide-chaîne
e*thirteen / e*spec Slider
Plateau
SCOTT custom spider / SRAM Eagle Transmission 34T chainring
Chaîne
SRAM CN GX Eagle Transmission
Cassette
SRAM Eagle XS 1270 Transmission 10-52
Freins
Shimano Deore M6120 4 Piston Disc
Disque de frein
Front: SM-RT64 CL 180mm / Rear: RT-EM600 CL 180mm
Cintre
Syncros Fraser 2.0 DC Alloy 6061 D.B.
mini Rise / back sweep 8° / 760mm
Syncros Performance XC lock-on grips
Potence
Syncros DC 2.0
Syncros Cable Integration System
0° rise / 6061 Alloy / 31.8mm / 1 1/8″
Tige de selle
Syncros Duncan Dropper Post 2.0
31.6mm / S & M size 125mm / L size 150mm / XL size 170mm
Selle
Syncros Tofino 2.0 Regular
CRMO rails
Jeu de direction
Syncros – Acros Angle adjust & Cable Routing HS System
+-0.6° head angle adjustment
ZS56/28.6 – ZS56/40 MTB
Moyeu avant
Formula CL-811 / 15x110mm
Moyeau arrière
Formula CL-148S / 12x148mm
Rayons
Stainless Black 15G / 1.8mm
Jante
Syncros X-30S / 32H / 30mm
Tubeless ready
Pneu avant
Schwalbe Wicked Will 29×2.4″ EVO
Super Race / TLE / 67EPI / Addix Speed Soft
Pneu arrière
Schwalbe Wicked Will 29×2.4″ EVO
Super Race / TLE / 67EPI / Addix Speed Grip
Extras
SRAM AXS Extension Cord
Poids en Kg (App.)
17.9
